IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 64
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Input Configuration (continued)
HDCP Authorized
Enable HDCP support
E
E
X!
*1HDCP
}
HdcpE
X!
*1
]
Enable HDCP encryption support for
input
X!
(default).
NOTE: HDCP Authorized is permanently enabled for DisplayPort IN1.
Disable HDCP support
E
E
X!
*0HDCP
}
HdcpE
X!
*0
]
Disable HDCP encryption support for
input
X!
.
View HDCP support status
E
E
X!
HDCP
}
R
X1)]
View HDCP encryption support status.
Input Aspect Ratio
Set for fill
EX!
*1ASPR
}
Aspr
X!
*1
]
Set input
X!
to always fill the entire
output raster (default).
Set to follow
EX!
*2ASPR
}
Aspr
X!
*2
]
Set input
X!
to maintain its current
native aspect ratio.
View aspect setting
EX!
ASPR
} X3(]
View current aspect ratio setting
X3(
for
input
X!
.
Active Pixels and Lines
View active pixels
EX!
APIX
} X*]
Verbose modes 2 and 3:
Apix
X!
*
X*]
View active pixels
X*
on input
X!
.
View active lines
EX!
ALIN
} X(]
Verbose modes 2 and 3:
Alin
X!
*
X(]
View active lines
X(
on input
X!
.
3:2, 2:2, and 24:1 Film Mode Detection
Auto
EX!
*1FILM
}
Film
X!
*1
]
Enable automatic film mode detection
for input
X!
(default).
Off
EX!
*0FILM
}
Film
X!
*0
]
Disable film mode detection for input
X!
.
View film mode setting
EX!
FILM
} X1)]
View the film mode setting for input
X!
.
KEY:
X!
= Input selection
1 = DisplayPort input 1
2-6 = HDMI or DVI input 2, 3, 4, 5, or 6
7-8 = DTP2/XTP input 7 or 8 (IN1808 Series only)
9 = Aux audio input
X*
= Active pixels
Response is four digits, padded with zeros.
X(
= Active lines
Response is four digits, padded with zeros.
X1)
= On or Off status
0 = Off or disabled
1 = On or enabled (default)
X3(
= Aspect ratio setting
1 = Fill — Each input rate fills the entire output raster (default).
2 = Follow — Each input rate is displayed with its native aspect
ratio.
