IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 77
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Advanced Configuration
Test Pattern
Set test pattern E
1*
X2@
TEST
}
Test1*
X2@]
Select a test pattern (
X2@
).
View test pattern E
1TEST
} X2@] View the currently selected test pattern.
Switch Effects
NOTE: Between input switches the audio ramps down and then up.
Set output switch effect
E
O1*
X4%
SWEF
}
SwefO1*
X4%]
Set the output switch effect to
X4%
.
View setting
E
O1SWEF
} X4%]
View the current output switch effect.
Upstream Video Switch Effects
Cut
E
U1*0SWEF
}
SwefU1*0
]
Set the upstream video switch effect to
Off.
Seamless cut
E
U1*1SWEF
}
SwefU1*1
]
Set the switch effect to seamless cut
(default): the last frame of video freezes
on the screen, then immediately cuts to
the newly selected input.
View setting
E
U1SWEF
} X4%]
Show current switch effect setting
X4%
.
Video Signal Presence
View signal presence
E
0LS
} X6!
*...*
X6!]
Verbose modes 2 and 3:
IN00•
X6!
*...*
X6!]
View video signal status
X6!
for inputs
1 through 6 (IN1806) or 1 through 8
(IN1808 Series).
Front Panel Lock (Executive Mode)
Enable lock
X2(
X Exe
X2(]
Set front panel lock mode
X2(
.
Disable lock mode
0X
Exe0
]
Unlock all front panel controls. All front
panel adjustments can be made.
View lock mode status
X
X2(]
View current lock mode status
X2(
.
KEY:
X2@
= Test patterns
0 = Off (default), 1 = Crop, 2 = Alternating pixels, 3 = Crosshatch,
4 = Color Bars, 5 = Crayscale, 6 = Audio test (crop pattern with
orbiting text AUDIO TEST and outputting pink noise at LPCM-2Ch,
48 Hz, 24-bit)
X2(
= Front panel lock (executive mode)
0 = Off or disabled (front panel controls fully accessible) (default).
1 = Mode 1 — Complete front panel lockout
2 = Mode 2 — Allows Input switching, logos, and volume control only
3 = Mode 3 — Allows Input switching and logos only
4 = Mode 4 — Volume control only
X4%
= Video switch effect
0 = Cut through black — The input instantly cuts to black, then cuts
to the newly selected input with no fading.
1 =
Fade through black —
The input fades to black before the
newly selected input fades in.
2 =
Seamless fade (default) —
Displays a final frozen frame of
the previous input while the newly selected input fades in.
3 = Seamless cut — The last frame of video freezes on the
screen, then cuts to the newly selected input.
Between input switches the audio ramps down and then up.
X6!
= Video signal status
0 = Video, TMDS, or DP signal not detected
1 = Video, TMDS, or DP signal detected
