IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 78
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Advanced Configuration (continued)
HDCP Output Mode
Set HDCP mode
E
S
X@
*
X4^
HDCP
}
HdcpS
X@
*
X4^]
Set the HDCP output mode
X4^
for
output
X@
.
View HDCP mode
E
S
X@
HDCP
} X4^]
View the HDCP output mode for output
X@
.
HDCP Notification
Set HDCP notification
E
N1*
X4&
HDCP
}
HdcpN1*
X4&]
Set the HDCP notification to
X4&
.
View HDCP notification
E
N 1 HDCP
} X4&]
View the HDCP notification selection.
HDCP Status
Query input
E
I
X!
HDCP
} X4$]
Request HDCP status
X4$
of input
X!
.
Query output
E
O
X@
HDCP
} X4$]
Request HDCP status
X4$
of output
X@
.
KEY:
X!
= Input
1 = DisplayPort input 1 (all models)
2-6 = HDMI or DVI inputs 2 through 6 (all models)
7-8 = DTP2/XTP inputs 7 and 8 (IN1808 Series only)
9 = Aux audio input
X@
= Output
1 = HDMI/DVI output 1A
2 = DTP2/XTP/HDBT output 1B
3 = HDMI/DVI Loop output
X4$
= HDCP status
0 = No sink or source device detected
1 = Sink or source detected but no HDCP present
2 = Sink or source detected with HDCP
X4^
= HDCP output mode
0 = Off — Disable all HDCP authentication and encryption attempts.
1 = Follow input (with a maximum of 10 seconds of authentication
trials, default)
2 = Encrypt output (with a maximum of 10 seconds of authentication
trials
3 = Follow input (with continuous authentication trials)
4 = Encrypt output (with continuous authentication trials)
X4&
= HDCP notification mode
0 = Black screen — Notification disabled (mute output)
1 = Green screen with OSD bug (orbiting message) (default)
2 = User image with black screen background
NOTE: A green screen with HDCP Content orbiting text or an HDCP user logo is visible only if a single HDCP
non-compliant display is attached, or if both attached displays are non-HDCP compliant. If the IN1806 and IN1808
Series is connected to one compliant and one non-compliant display at the same time, only a green or black screen
with no text or logo appears on the non-compliant display.
