IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 79
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Advanced Configuration (continued)
Twisted Pair Protocol
Set input TP type
(IN1808 Series only)
E
I
X!
*
X6&
HDBT
}
HdbtI
X!
*
X6&]
Set the TP protocol for input
X!
to
X6&
.
(
X!
can be 7 or 8 only.)
View input TP protocol
(IN1808 Series only)
E
I
X!
HDBT
} X6&]
View current TP protocol setting for input
X!
.
Set output TP protocol
E
O 2*
X6&
HDBT
}
HdbtO
X@
*
X6&]
Set the TP protocol for DTP2/XTP/HDBT
Output 1B (2) to
X6&
.
View output TP protocol
E
O 2HDBT
} X6&]
View current TP protocol setting for
output 1B.
KEY:
X!
= TP input
7 = DTP2/XTP input 7, 8 = DTP2/XTP input 8
X6&
= DTP protocol setting
0 = DTP format (default)
1 = XTP format
2 = HDBaseT format (output only)
DTP Remote Power Parameters
ATTENTION:
• Ensure that the correct remote DTP power setting is used. Sending DTP2 power to a DTP (series 1) endpoint can
result in hardware damage. Enable DTP2 power only to a compatible DTP2 endpoint.
• Assurez-vous de bien régler l’alimentation DTP à distance. L’envoi d’une alimentation DTP2 à un point de connexion
DTP (ancienne gamme) peut provoquer des dommages matériels. Assurez une alimentation DTP2 uniquement vers un
point de connexion DTP2 compatible
Set input remote power
(IN1808 Series only)
E
I
X!
*
X6^
RPWR
}
RpwrI
X!
*
X6^]
Set the remote power on input
X!
to
X6^
.
(
X!
can be 7 or 8 only.)
View input remote power
(IN1808 Series only)
E
I
X!
RPWR
} X6^]
View remote power setting for input
X!
.
Set output remote power
E
O 2*
X6^
RPWR
}
RpwrO 2*
X6^]
Set the remote power for output 1B (2)
to
X6^
.
View output remote power
E
O 2 RPWR
} X6^]
View remote power setting for output 1B.
KEY:
X6^
= DTP remote power status
0 = No remote power (default)
1 = DTP – 12 VDC
2 = DTP2 – 48 VDC
Resets
System reset (soft reset)
E
ZXXX
}
Zpx
]
Reset all device settings to factory
defaults
Absolute system reset
E
ZQQQ
}
Zpq
]
Set all device settings plus DHCP and
the IP address to factory defaults.
DHCP = Off, IP address =
192.168.254.254.
This command also removes the
initial serial number password that is
set at the factory and resets it to no
password.
Absolute system reset, retain
IP settings
E
ZY
}
Zpy
]
Same as absolute system reset except
that IP address, subnet mask, gateway
address, DHCP, and port mapping are
not reset.
Erase user-supplied web
page and files
24 28
E
<lename>EF
}
Del•<lename>
]
