IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 80
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Advanced Configuration (continued)
Resets (continued)
Erase current directory and
its files
24 28
E
/EF
}
Ddl
]
Erase current directory and
subdirectories
24 28
E
//EF
}
Ddl
]
Erase flash memory
24
E
ZFFF
}
Zpf
]
Serial Port Configuration
Set serial port parameters
EX5&
*
X5*
,
X5(
,
X6)
,
X6!
CP
}
Cpn
X5&
•Ccp
X5*
,
X5(
,
X6)
,
X6!]
Set the Remote RS-232 port
parameters.
View the serial port
parameters
EX5&
CP
} X5*
,
X5(
,
X6)
,
X6!]
Verbose modes 2 and 3:
Cpn
X5&
•Ccp
X5*
,
X5(
,
X6)
,
X6!]
View port parameters
X5*
,
X5(
,
X6)
, and
X6!
of port
X5&
.
Set UART start point
EX6%
MD
}
Pmd
X6%]
Set the port number start point for the
over TP Universal asynchronous receiver-
transmitter (UART).
View UART start point
E
MD
} X6%]
View the port number start point for the
over TP UART.
NOTE: The remote power state for HDBT and XTP modes is forced to Off (0). Attempts to change the power setting while
the unit is not in DTP mode result in an E14 (Not valid for current configuration) error message.
KEY:
X5&
= Remote port number
1 = Remote port (3-pole captive screw)
7 = Universal asynchronous receiver-transmitter (UART) on TP input 7
(IN1808 Series only)
8 = Universal asynchronous receiver-transmitter (UART) on TP input 8
(IN1808 Series only)
9 = UART on TP output 1B
X5*
= Baud rate of port
300, 600, 1200, 1800, 2400, 3600, 4800, 7200, 9600 (default),
14400, 19200, 28800, 38400, 57600, 115200
X5(
= Parity
Odd, Even, None (default), Mark, Space (only the first letter is required).
X6)
= Data bits
7 or 8 (default)
X6!
= Stop bits
1 (default) or 2
X6%
= UART port start point
Start point for UART ports:
Rear panel RS-232 =
X6%
.
TP IN 7 =
X6%
+ 1 (IN1808 Series only)
TP IN 8 =
X6%
+ 2 (IN1808 Series only)
TP OUT 1B =
X6%
+ 3
Default = 2000 (meaning IN7 = 2001, IN8 = 2002, OUT1B = 2003)
