IN1806 and IN1808 Series Scaling Presentation Switchers • SIS Configuration and Control 81
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Backup and Restore Configuration
Save unit configuration
E
1*
X8%
XF
}
Cfg1*
X8%]
Back up the current unit configuration as
type
X8%
to a file in the unit file system.
Restore unit configuration
E
0*
X8%
XF
}
Cfg0*
X8%]
Restore the saved configuration, type
X8%
.
KEY:
X8%
= Configuration type
0 = IP configuration (ip.cfg)
2 = Unit-specific parameters (box.cfg)
NOTE: Configuration files are stored in the directory /nortxe-backup, created on the unit by the Save command.
Information Requests
General information
X!
*I Vid
X!
•Typ
X#
•Amt
X1)
•Vmt
X4@
•Hrt
X1#
•Vrt
X1#]
Verbose modes 2 and 3:
Inf00*Vid
X!
•Typ
X#
•Amt
X1)
•Vmt
X4@
•Hrt
X1#
•Vrt
X1# ]
View video input signal type, audio mute
status, video mute status, and horizontal
and vertical frequencies.
Query model name
1I
X3%]
Verbose modes 2 and 3:
Inf01*
X3% ]
View the unit model name (
X3%
).
Query unit description
2I
Scaling•Presentation•Switcher
]
Verbose modes 2 and 3:
Inf02*Scaling•Presentation•Switcher
]
View the IN1806 or IN1808 Series
product description.
Query firmware version
Q
n.nn
]
Verbose modes 2 and 3:
Ver01*n.nn
]
View the unit firmware version to the
second decimal place.
Query full firmware version
*Q
n.nn.nnnn
]
Verbose modes 2 and 3:
Bldn.nn.nnnn
]
View the unit firmware version with its
build number.
Query part number
N
X3^]
Verbose modes 2 and 3:
Pno
X3^]
View unit part number
X3^
for the model.
KEY:
X!
= Input selection
1 = DisplayPort input 1 (all models)
2-6 = HDMI or DVI inputs 2 through 6 (all models)
7-8 = DTP2/XTP inputs 7 and 8 (IN1808 Series only)
9 = Aux audio input
X#
= Digital video format
0 = No signal, 1 = DVI, 2 = HDMI, 3 = DisplayPort
X1)
= On or off, enable or disable
0 = Audio unmuted, 1 = Audio muted
X1#
= Horizontal and vertical frequencies
nnn.nn. Response is three digits with two decimal places.
X3%
= Model name
IN1806, IN1808, IN1808 IPCP MA, or IN1808 IPCP SA
X3^
= Part number
IN1806 — 60-1663-01
IN1808 (base model) — 60-1615-01
IN1808 IPCP SA — 60-1615-02
IN1808 IPCP MA 70 — 60-1615-03
X4@
= Video output mute
0 = Unmuted, 1 = Muted to black screen, 2 = Muted video and sync
