IN1806 and IN1808 Series Scaling Presentation Switchers • Operation 37
Output Resolutions and Refresh Rates
Resolution 23.98 Hz 24 Hz 25 Hz 29.97 Hz 30 Hz 50 Hz 59.94 Hz 60 Hz
640x480 X
800x600 X
1024x768 X
1280x768 X
1280x800 X
1280x1024 X
1360x768 X
1366x768 X
1440x900 X
1400x1050 X
1600x900 X
1680x1050 X
1600x1200 X
1920x1200 X
480p X X
576p X
720p X X X X X X
1080i X X X
1080p X X X X X X X X*
2048x1080 (2K) X X X X X X X X
2048x1200 X
2048x1536 X
2560x1080 X
2560x1440 X
2560x1600 X
3840x2160 X X X X X
X** X** X**
4096x2160 X X X X X
X*** X*** X***
* Default output resolution
** Rate supported on HDMI output or to DTP2 endpoints only.
*** Rate supported on HDMI output only.
• HDMI 1A Format — Select HDMI 1A Format or TP 1A Format from the list of Output
submenu items, then press the

or  buttons to select the output format. The format
choices include:
• Auto (based on the EDID of the sink) (default)
• DVI RGB 444
• HDMI RGB 444 Full
• HDMI RGB 444 Ltd
• HDMI YUV 444 Ltd
• HDMI YUV 422 Ltd
