XTP CrossPoint Series • Programming Guide 97
Command Function
SIS Command
(Host to Unit to Endpoint)
Response
(Endpoint to Unit to Host)
Additional Description
XTP T HDMI , XTP T HD 4K, XTP T HWP 101, XTP T HWP 101 4K, and XTP FT HD 4K
transmitter commands
Audio routing selections
Input audio selection
E
I
X^
*
X1!
AFMT
}
AfmtI
X^
*
X1!]
Use audio from the
X1!
source.
Example 1:
E
I1*1AFMT
}
AfmtI01*1
]
Use digital audio from the HDMI port of
input 1.
Example 2:
E
I1*0AFMT
}
AfmtI01*0
]
Auto (0): Digital audio takes priority over
analog audio.
View input audio selection
E
I
X^
AFMT
} X1!]
View all input audio selections
E
IAFMT
} X1!
1
X1!
2
X1!
3
...
X1!
n
]
16 or 32 (
n
) sequential audio input
selections, starting from input 1.
Enable black signal for XTP T
endpoint
E
E
X^
*1AFMT
}
AfmtE
X^
*1
]
Enable an audio only tie for the
connected XTP transmitter.
Disable black signal for XTP T
endpoint
E
E
X^
*0AFMT
}
AfmtE
X^
*0
]
Disable an audio only tie for the
connected XTP transmitter.
View black signal output status for
XTP T endpoint
E
E
X^
*AFMT
} X2@]
The black signal status of XTP
transmitter endpoint
X^
is
X2@
.
Input reports as an HDCP-authorized device
HDCP authorized device on
E
E
X^
*1HDCP
}
HdcpE
X^
*1
]
Set the input as an HDCP authorized
device.
HDCP authorized device off
E
E
X^
*0HDCP
}
HdcpE
X^
*0
]
Set the input as not an HDCP
authorized device.
View HDCP authorized status
E
E
X^
HDCP
} X1@]
Show HDCP authorized device status.
HDCP status
View input HDCP status
E
I
X^
HDCP
} X1#]
View HDCP status of all inputs
E
I*HDCP
} X1#
1
X1#
2
X1#
3
...
X1#
n
]
Input sync detection
View all input connections
0LS
X%
1
X%
2
X%
3
...
X%
n
]
16 or 32 (n)
X%
s; each is the
connection status of an input, starting
from input 1.
Example (XTP II CrossPoint
3200):
0LS
Input:
Response Status:
No input detected
Sync detected Sync detected
1 2345
6
7 8 9
1011
12
13
32
0 0 0 1 1 1 0 1 0 0 1 0 1. . .0
NOTE: X% = Input signal status 0 = No signal detected 1 = Signal detected
X^ = Input number (for other than tie) 01 – 16 or 32
X1! = Input audio source 0 = Auto (see the example above) 2 = Analog 2-channel audio
1 = HDMI (de-embedded digital audio) (default)
X1@ = HDCP authorized device 0 = off 1 = on (default)
X1# = HDCP status (for inputs) 0 = No source device connected
1 = Source connected is HDCP-compliant
2 = Source connected is not HDCP-compliant
X2@
= Enable or disable
0 = Disable 1 = Enable (default)
(for black video ties)
