Installation manual
CNC 8060
CNC 8065
(REF: 1402)
·7·
ABOUT THE PRODUCT
BASIC CHARACTERISTICS.
(*) Differential TTL / Sinusoidal 1 Vpp (**) TTL / Differential TTL / Sinusoidal 1 Vpp / SSI protocol
Basic characteristics. 8060 M 8060 T 8065 M 8065 T
PC-based system. Closed system Open system
Operating system. Windows XPe Windows XP
Number of axes. 3 a 5 3 to 28
Number of spindles. 1 2 1 to 4
Number of tool magazines. 1 2 1 to 4
Number of execution channels. 1 2 1 to 4
Number of handwheels. 1 a 3 1 to 12
Type of servo system. Analog / Sercos Digital Analog / Digital Sercos /
Digital Mechatrolink
Communications. RS485 / RS422 / RS232
Ethernet
Integrated PLC.
PLC execution time.
Digital inputs / Digital outputs.
Marks / Registers.
Timers / Counters.
Symbols.
< 1ms/K
1024 / 1024
8192 / 1024
512 / 256
Unlimited
Block processing time. < 1.5 ms < 1 ms
Remote modules. RIOW RIO5 RIO70 RCS-S
Communication with the remote modules. CANopen CANopen CANfagor Sercos
Digital inputs per module. 8 16 / 32 16 - - -
Digital outputs per module. 8 24 / 48 16 - - -
Analog inputs per module. 4 4 8 - - -
Analog outputs per module. 4444
Inputs for PT100 temperature sensors. 2 2 - - - - - -
Feedback inputs. - - - - - - 4 (*) 4 (**)
Customizing (on an open system only).
PC-based open system, fully customizable.
INI configuration files.
FGUIM visual configuration tool.
Visual Basic®, Visual C++®, etc.
Internal databases in Microsoft® Access.
OPC compatible interface
