RESTRICTED USE ONLY Fargo Electronics, Inc.

DTC400 Card Printer/Encoder User Guide (Rev. 2.2)

3-26

Installing the Printer Driver (continued)

Step Procedure

Click on the Finish button to complete the Fargo Add Printer Wizard.
