Chapter 5: System Software
5-9
System Key 5
* Current Container Type 1-32 1
* Last Reject Detected
* Beacon Status On/Off/High Priority On
* Line Speed (cpm) 0-2500 cpm
* Line Speed (cph) 0-150,000 cph
* System Display Calibrate/Operate Operate
° Conveyor Drive Sprocket 18-29 Teeth 25 Teeth
° Serial Data ID Number 1-62
° Host Modbus Port Status LC=, RX=, TX=
° Modbus Message Counters OK, Bad, Other
° PLC Output Pulse Width 0-120 ms 50 ms
° Time Width Of Can 0-65,000 ms
° Chain Velocity 0-300 mpm
° Alarm Underfill On/Off Off
° Alarm Overfill On/Off Off
° Alarm Missing Lid On/Off Off
° Alarm Bulged End On/Off Off
° Alarm Down Can On/Off Off
° Alarm Dia. Missing Lid On/Off Off
° Alarm External Reject On/Off Off
° Load Default Constants Execute
° Can Width At Trig 1-250 37 mm
° Maximum Can Diameter 1-400 62 mm
° Maximum Line Speed 1500 cpm 1000 cpm
° Maximum Conveyor Speed 21-120 mpm 74 mpm
° Change Password 3 digits, numbers 1-6 222
° View TB1&4 Pin Assignments Execute
° View PLC Pin Assignments Execute
‡ Clear System Execute
Function Group Function Name Parameter Default
5
Industrial Dynamics Company, Ltd. Document 40255-0600
