Fimap IMx - 2 Main Technical Features

2-11
Chapter 2
Main Technical Features
TECHNICAL DESCRIPTION U/M IMx BB IMx B IMx BT
Maximum Ramp Gradient % 2 2 2
Steering Diameter mm 1700 1700 1700
Machine Length mm 1200 1200 1200
Machine Height mm 1030 1030 1030
Machine Width (without squeegee) mm 570 570 570
Machine Weight (empty and without batter-
ies)
kg 69 69 76
Gross Weight of the machine in work condi-
tions (machine + batteries + water)
kg 163 163 170
Weigths and Pressures
1
Weight on front right wheel kg 51.90 ÷ 74.00
Touching surface of the front right wheel cm
2
8.41 ÷ 10.32
Pressure made by the front right wheel
kg
cm
2
5.76 ÷ 7.83
Weight on front left wheel kg 46.10 ÷ 69.30
Touching surface of the front left wheel cm
2
7.79 ÷ 9.66
Pressure made by the front left wheel
kg
cm
2
5.42 ÷ 8.54
Weight on rear wheel kg 10.50 ÷ 44.30
Touching surface of the rear wheel cm
2
0.41 ÷ 0.91
Pressure made by the rear wheel
kg
cm
2
16.49 ÷ 51.64
1
Weight and Pressures depends on how much water there is in the tanks and on what type of battery the
machine fits.
