Fimap IMx - Suggested Spare Parts

8-82
8.5 Technical Features
TECHNICAL DESCRIPTION U/M IMx BT
Traction motor Voltage V 24
Traction motor Power W 150
Traction motor Consumption at a constant speed
on flat
A 27.6 ± 1
Traction wheel [number / (diameter / width)] Nr / (φ mm / mm) 2/225/64
Traction wheel material Thermoplastic Polyurethane
Traction wheel hardness Sh 80
Maximum forward speed km/h 3.9
Maximum reverse speed km/h 2.1
8.6 Consumable spare parts
iMx
PN Description BB B BT
436222 FRONT WHEEL D=175 d=20 S=60 WITH BEARINGS
√ √
438029 FRONT WHEEL D=175 d=20 S=60 SPLINED HUB
√
427251 WHEEL D=80 L=23
√ √ √
Carbon Brushes
409413 TRACTION MOTOR CARBON BRUSHES
√
8.7 Suggested spare parts
iMx
PN Description BB B BT
223329 TRACTION MOTOR 24V 150W
√
