Fimap IMx - Technical Features; Recommended Spare Parts

5-66
5.15 Technical Features
TECHNICAL DESCRIPTION U/M IMx BB IMx B IMx BT
Dimension of Battery compartment (l x L x h) mm 353x333x250
Batteries Rated Voltage
V
Ah
2x(12/77)
Maximum batteries weight (battery 12V 77Ah) kg 2x26,5
5.16 Recommended Spare Parts
iMx
PN Description BB B BT
412123 HOSE FASTENING SPRING D=38 ABS
√ √ √
437657 CHARGER NE286 24V 11A
√ √ √
210516 COMPLETE KEY SWITCH (ELFI D.22)
√ √
436267 CONTROL CARD
√ √
438057 MAIN CARD IMX COD.7CFS0000
√ √
438158 POTENTIOMETER
√
407578 DOUBLE REMOTE CONTR SW. 24V 100A SW84-P
√
407580 RELAY FINDER 65.31 30 A, 24 V SUCT. MOT.
√
409607 FUSE 30A
√
409612 FUSE 50A
√
426356 ELECTRONIC HOURMETER D=51,5 L=49
√
438351 SWITCH BLACK 16A FASTON 6.3
√
438352 SWITCH 16A FASTON 6.3
√
434431 SWITCH ON-MOM 645H/2 10A 250V
√
