Fimap IMx - Technical Features

6-71
6.5 Technical Features
TECHNICAL DESCRIPTION U/M IMx BB IMx B IMx BT
Working width mm 508 508 508
Working capacity, up to m2/h 2032 2032 2032
Number of brushes Nr 1 1 1
Maximum diameter of the active part of the brush φ mm 508 508 508
Brush turns rpm 166 166 166
Brush motor voltage V 24 24 24
Brush motor power W 500 500 500
Max weight on brush kg 25 25 25
6.6 Consumable Spare Parts
PN Bristle type φ Bristle (mm) Bristle colour φ Brush (mm) Description
404654 PPL 0.3 Blue 508 BRUSH PPL 0.3
405631 PPL 0.6 White 508 BRUSH PPL 0.6
404653 PPL 0.9 Black 508 BRUSH PPL 0.9
405632 ABRASIVE 0.9 - 560 BRUSH TYNEX
405527 - - - 500 PAD HOLDER
Carbon Brushes
422462 - - - - BRUSH MOTOR CARBON BRUSHES
6.7 Recommended Spare parts
iMx
PN Description BB B BT
223301 GEAR MOTOR 24V 500W 140RPM H2O W/MOLEX
√ √
436120 BASE BUMPER WHEEL D=100 H=20
√ √
437859 BRUSH FLANGE
√ √ √
438300 GEAR MOTOR 24V 500W 140RPM THREADED SHAFT.
√
