Fimap IMx - Pumps Sets; Vacuum Sets

5-63
Pumps Sets
Parameter Default Min ÷ Max Description
Pumps Sets:
Wtr Lev1: ### [V]
10.0 5 ÷ 24 First level of water flow of the proportional solenoid valve.
Pumps Sets:
Wtr Lev2: ### [V]
11.0 5 ÷ 24 Second level of water flow of the proportional solenoid valve.
Pumps Sets:
Wtr Lev3: ### [V]
13.5 5 ÷ 24 Third level of water flow of the proportional solenoid valve.
Pumps Sets:
Wtr Lev4: ### [V]
16.0 5 ÷ 24 Fourth level of water flow of the proportional solenoid valve.
Pumps Sets:
Wtr Lev5: ### [V]
20.0 5 ÷ 24 Fifth level of water flow of the proportional solenoid valve.
Vacuum Sets
Parameter Default Min ÷ Max Description
Vacuum Sets:
I Max: ## [Amp]
40 10 ÷ 40 Maximum current from the main card to the vacuum motor.
Vacuum Sets:
I Nom: ## [Amp]
20 5 ÷ 25 Rated current; with T Nom manages the amperometric protection
(alarm + stop vacuum motor).
Vacuum Sets:
T Nom: ## [s]
10 1 ÷ 10 Rated timer; with I Nom manage the amperometric protection (alarm
+ stop vacuum motor).
Vacuum Sets:
T Off: ## [s]
5 0 ÷ 30 Delay of switching on of the vacuum motor when the switch is
pressed.
Vacuum Sets:
T Off stop: ## [s]
15 0 ÷ 100 Delay of switching off of the vacuum motor when the safety lever is
released
Vacuum Sets:
Eco Speed: ## [V]
17 15 ÷ 20 Value of Voltage reduction of vacuum motor, during ECO mode
