7.5 Technical Features
TECHNICAL DESCRIPTION U/M IMx BB IMx B IMx BT
Squeegee width mm 705 705 705
Vacuum Motor Stages Nr 2 2 2
Squeegee adapter type Vertical Vertical Vertical
Vacuum Motor Power W 310 310 310
VAcuum Motor Voltage V 24 24 24
Vacuum Motor Depression mmH
2
O 610 610 610
Recovery Tank l 37 37 37
7.6 Consumable Spare Parts
iMx
PN Description BB B BT
219451 KIT SQUEEGEE BLADES 33 SHORE
√ √ √
219452 KIT SQUEEGEE BLADES 40 SHORE PU
√ √ √
219453 KIT SQUEEGEE BLADES LATEX
√ √ √
438487 WHEEL
√ √ √
Carbon Brushes
424210 VACUUM MOTOR CARBON BRUSHES
√ √ √
7.7 Recommended Spare Parts
iMx
PN Description BB B BT
436120 BUMPER WHEEL D=100 H=20
√ √ √
430957 STRAINGHT ADAPTER D=40
√ √ √
438262 GAS SPRING 100N L=274
√ √ √
223322 VACUUM MOTOR ASSY MOLEX
√ √
223250 VACUUM MOTOR ASSY ANDERSON
√
433652 FLOATER PROTECTION D.110 x 182
√ √ √
412363 CARTRIDGE FILTER ASSEMBLY D=60 H=130
√ √ √
434151 HOSE D.38X815 D.50 W/CAP
√ √ √
437956 HOSE D.38X1200
√ √ √
