4.4.6 Parking Brake IMx BT
• Put the machine in safe conditions.
• Remove the screws that secure the
Support Bracket of the Parking
Brake to the machine frame (see fig.
4.4.6-87).
• Remove the Parking Brake from its
Support Bracket.
• Proceed at reverse to refit the part.
4.4.6-87
