Fimap IMx - Check; Monitor

5-65
Check / Monitor
Check / Monitor:
I Tr: ### [Amp]
Show current of traction motor (IMx BT only)
Check / Monitor:
I Br: ## [Amp]
Show current of brush motor .
Check / Monitor:
I Vac: ## [Amp]
Show current of vacuum motor .
Check / Monitor:
V Tr: #### [V]
Show voltage of traction motor (IMx BT only).
Check / Monitor:
V Batt: #### [V]
Show battery voltage.
Check / Monitor:
Vref: #.# [V]
Show the voltage reference of the potentiometer (IMx BT only).
Check / Monitor:
Wtr Pump: ### [%]
Show % speed of water pump.
Check / Monitor:
Det Pump: ### [%]
Show % speed of chemical pump.
Check / Monitor:
BR Temp: ## [C]
Show temperature inside of main card, related to brush/vacuum.
Check / Monitor:
TR Temp: ## [C]
Show temperature inside of main card, related to traction (IMx BT only).
Check / Monitor:
TR Ovrld: ### [%]
Show the percentage value of the amperometric protection of traction motor (when 100%
the amperometric protection cuts the current).
