flexfactory ag Quick Setup Guide and User’s anyfeed SX Series 16
3 INSTALLATION
3.1 INTRODUCTION
This chapter describes the installation procedure for the anyfeed SX. Additional equipment
required for a complete flexible feeding system is not covered in this manual.
3.2 MECHANICAL INSTALLATION
Feeder must be bolted or clamped down to base plate at any
time during operation. Due to its working principle, feeder may
“walk off” the table during operation if not properly attached to
base plate.
Do not connect the feeder to elecrical power or compressed air
before it is securely bolted/ clamped down to base plate.
Prepare the mounting hole pattern as shown on the next pages. At least 650 mm of the
feeder’s base housing must rest on the base plate. Note that the anyfeed SX 240 and the
anyfeed SX 160 have different dimensions, the mounting hole pattern however is the
identical.
