flexfactory ag Quick Setup Guide and User’s anyfeed SX Series 46
6. Now the FOV support plate can be installed in the feeder. Before doing this, remove the
protective foil from the plate.
Figure 7-6 FOV support plate and screws
Figure 7-7 Feeder before installing the FOV support plate
7. Install the FOV support plate with the provided screws.
Do not tighten the screws too hard!
Otherwise the plate may warp or crack.
Figure 7-8 Slide in the FOV support plate
Figure 7-9 Tighten down the FOV support plate
