flexfactory anyfeed SX Series User Manual

flexfactory ag Quick Setup Guide and User’s anyfeed SX Series 44
7 FOV SUPPORT PLATE
For the SX240 you can order and install an FOV support plate, if it does not already have one.
On the following pages this procedure is described. The scope of delivery includes the plate
and 9 screws.
Im SX240 kann, falls noch nicht vorhanden, nachträglich eine FOV-Supportplatte bestellt and
eingebaut werden. Im Folgenden werden die nötigen Schritte erklärt. Im Lieferumfang sind
eine Platte and 9 Schrauben enthalten.
Warnung
Follow proper lockout procedures before performing this
service procedure. Failure to do so could result in injury.
1. Dismount the faceplate in
the front of the feeder.
Figure 7-1 Face plate of the feeder
2. Dismount the bunker
together with the blue
bridge.
Figure 7-2 Dismount the bunker
