Flintec EM100-C User Manual

EM100-F User Manual
0084293
Page 10 of 93
2. Specification
EM100-F
Application
Bottling/Filling
Bridge Excitation
+5V
DC
Load-Cell/Sensor
4-Wire or 6-Wire
Accuracy Class
X(0,2); X(0,5); X(1); X(2)
Weighing Range
Single Interval, Multi-Range or Multi-Interval
Verification Scale Interval
10,000
Minimum Input Sensitivity
0.05µV/Count
Certified Accuracy
0.3µV/vsi
Resolution (External)
±350,000 counts
Minimum Load Cell Impedance
58.3Ω (1x350Ω; 4x350Ω; 4x1100Ω; 6x350Ω)
Maximum Load Cell Impedance
1100Ω
Maximum Analogue Input Range
±15mV Bipolar (±3mV/V @ +5V
DC
Excitation)
Conversion Rate
75sps to 1200sps (Dependent on Settings)
Communication Protocols
USB CDC (Config & Setup Only)
RS-232 (N-bits, Parity, Stop-bit)
9.6k, 14.4k, 19.2k, 38.4k, 57.6k, 115.2k, 230.4k,
& 460.8kbits/s (8-N-1)
RS-485 (Half & Full-Duplex)
9.6k, 14.4k, 19.2k, 38.4k, 57.6k, 115.2k, 230.4k,
& 460.8kBits/s
CANopen Data Rate 10k, 20k, 50k, 125k, 250k, 500k, 800k, 1MBit/s
Power Supply
+9.6V
DC
to +32V
DC
Digital Input (30V
DC
max, >10kΩ
Input Impedance)
2
Digital Output (Open-Drain
+30V
DC
max, 300mWmax)
2
Filter Mode
Selectable FIR/IIR Filters
Calibration
Software Calibration & Setup
Weight/Measurement Functions
Zero; Gross; Tare; Net; Filter etc.
Operating Temperature Range
-15°C to +55°C
Storage Temperature
-30°C to +70°C
Regulations/Standards
OIML R-61-1:2006 & EN 45501:2015
Dimensions (L x W x D in mm)
80 x 40 x 16.6mm
DIN Rail Mounting
Optional Adaptor Board Available
IP Protection Rating
IP20

Flintec EM100-C Specifications

General

Brand	Flintec
Model	EM100-C
Category	Control Unit
Language	English
