EM100-C User Manual
0084292
Page 59 of 81
5.13. Re-Trigger Commands – RW, TT, TS, DT, TW, TI, HT
Note: All changes to the trigger commands must be stored in non-volatile memory using the ‘WP’
command.
5.13.1. RW Re-Trigger Window
This command defines a trigger window in unit d (digits) around the current cycle average value. If
the signal leaves this window even for one sample, then the averaging over the time-period ‘TT’ will
be started again. The automatic re-trigger function is required to define a short-time averaging
period (command ‘DT’) before you can use this function.
Master Sends
Slave Responds With
Meaning
RW↵
R+65535
Request: RW=65535dec.
RW 500↵
OK
Setup: RW=500dec.
Factory Default: 65535dec.
5.13.2. TT Average Time for Re-Trigger Function
This command defines an averaging time for calculating the cycle average value. If this time-period
has elapsed, the measurement cycle will be finished at the latest. The setting TT=0 disables the re-
trigger function.
Master Sends
Slave Responds With
Meaning
TT↵
T+65535
Request: TT=65535ms.
TT 300↵
OK
Setup: TT=300ms.
Factory Default: 65535 [65535ms].
5.13.3. TS Stop Value for Re-Trigger Function
This command defines the stop criteria in unit d (digits) for the re-trigger function. If the signal falls
below the ‘TS’ value, the measurement cycle will finish.
Master Sends
Slave Responds With
Meaning
TS↵
T+00000
Request: TS=0d.
TS 480↵
OK
Setup: TS=480d.
Factory Default: 0dec.
