EM100-F User Manual
0084293
Page 45 of 93
5.6.6. GW Get Data String (Net, Gross & Status)
Issuing the GW’ command, which has no parameters, will return the net weight, the gross weight,
the status and the checksum values, all combined into one single string in the format:
W+000100+001100010F
The first two sections of the return string comprise the net weight and gross weight results, followed
by two hexadecimal characters, which represent two bit-mapped status indicators. The last two
hexadecimal characters represent the checksum, which is the inverse of the sum of all the ASCII
values of the string, not including the checksum characters.
W
+000100
+001100
0
1
0F
Leading
Character
signifies the
GW
Net Weight
excluding
decimal
point.
Gross
Weight
excluding
decimal
point.
First Status
Nibble
Second
Status
Nibble
Checksum
STATUS
Value=1
Value=2
Value=4
Value=8
Status Bit-1
Not Used
Not Used
Output 1 Active
Output 2 Active
Status Bit-2
Signal Stable
Set Zero Performed
Tare Active
Not Used
The check sum is the complement value of the sum of all ASCII values within the data string without
the check sum itself.
Master Sends
Slave Responds With
Meaning
GW
W+000100+0011005109
(example)
Net Value: +000100dec. (no decimal point)
Gross Value: +001100dec. (no decimal point)
Status bit 1: 5hex. (Not Used).
Status bit 2: 1hex.
Checksum: 09hex.
