EM100-C User Manual
0084292
Page 56 of 81
5.11. Save Calibration & Setup Data Commands – CS, WP, SS
The calibration and setup parameters can be divided in 3 groups:
Calibration: ‘CE’, ‘CM’n’’, ‘CI’, ‘MR’,‘DS’, ‘DP’, ‘CZ’, ‘CG’, ‘ZT’, ‘FD’, ‘IZ’, ‘ZR’, ‘ZI’, ‘TM’, ‘TN’, ‘ZN’,
‘WT’ & ‘OF’ saved by command ‘CS’.
Setup: ‘FL’, ‘FM’, ‘UR’, ‘NR’, ‘NT’, ‘AD’, ‘NA’, ‘NS’, ‘BR’, ‘DX’, ‘TD’, ‘CTR’, ‘STR’, ‘SBR’, ‘SD’,
‘MT’, ‘TE’, ‘TL’, ‘RW’, ‘TT’, ‘TS’, ‘DT’, ‘TW’, ‘TI’, ‘HT’, saved by command ‘WP’.
Set-Points: ‘S0’, ‘S1’, ‘H0’, ‘H1’, ‘A0’, ‘A1’ saved by command ‘SS’.
Note: Calibration data can only be saved if the TAC code is known and precedes the ‘CS’
command. The setup data and the set-point data will be stored non-volatile memory using the ‘WP’
& ‘SS’ commands.
5.11.1. CS Save Calibration Data
This command results in the calibration data being saved causing the TAC to be incremented.
Master Sends
Slave Responds With
Meaning
CE↵
E+00013
Request: TAC Counter CE13.
CE 13↵
OK
Calibration Sequence Active.
CS↵
OK
Calibration Values Saved.
The ‘CS’ command saves changes made using ‘Calibration’ group commands. The Output Format
command ‘OF’ is also included. The command returns ‘ERR’ unless it is preceded by the ‘CE xx’.
5.11.2. WP Save Setup Parameters
The settings of the following groups, ‘Filter’ (‘FL’, ‘FM’, ‘UR’), ‘No-motion’ (‘NR’, ‘NT’),
‘Communications’ (‘AD’, ‘NA’, ‘NS’, ‘BR’, ‘DX’, ‘TD’, ‘CTR’, ‘STR’, ‘SBR’), ‘Trigger’ (‘SD’, ‘MT’, ‘TE’,
‘TL’) & ‘Re-Trigger’ (‘RW’, ‘TT’, ‘TS’, ‘DT’, ‘TW’, ‘TI’, ‘HT’) will saved the new settings using the ‘WP’
command.
Master Sends
Slave Responds With
Meaning
WP↵
OK
Setup Data Saved.
5.11.3. SS Save Set-Point Parameters
The set-points (S’n’), set-point hysteresis (H’n’) and set-point allocation (A’n’) will be saved using
the ‘SS’ command.
Master Sends
Slave Responds With
Meaning
SS↵
OK
Set-Point Parameter Saved.
