The status of the outputs can be
changed by issuing the ‘
IO
’ command with the
appropriate 4
-
digit
code e.g. IO 0001. The
status of the logic outputs is normally determined
by the internal set
-
points
or manually sett
ing the ‘
IO
’ and ‘
OM
’
(or ‘
IM
’)
output mask.
Master Sends
Slave Responds With
Meaning
IO 10
↵
OK
Set Output 1 Set.
IO 11
↵
OK
Set Outputs 1& 2 Set.
