Flintec EM100-C - Getting Started; Labelling

EM100-C User Manual
0084292
Page 11 of 81
3. Getting Started
You will require:
• PC or PLC with RS-232, RS-485 or CANopen communication ports.
• Load-cell/scale with test weights or a load-cell simulator.
• +12V
DC
to +24V
DC
power supply capable of delivering approximately 200mA.
• A suitable ASCII communication software e.g. Hyper-Terminal, Putty, TeraTerm etc. or
Flintec Device Configuration (FDC) application software. Download the latest copy of FDC
from the Flintec website (www.flintec.com
).
Note: The Flintec FDC application was developed in-conjunction with the ‘Peak System’ USB
to CAN adaptor. If using the CANopen interface AND the FDC application, only use the ‘Peak
System’ adaptor. See website below for more details. For all other interfaces listed above,
generic adaptors can be used in accordance with the manufacturer’s instructions and drivers.
https://www.peak-system.com/PCAN-USB.199.0.html?&L=1
3.1. Labelling
