5.6.7. GA Get Triggered Average Value
This command reads the measurement result of a measurement cycle. The measurement value
has been averaged according the defined measuring time.
Master Sends
Slave Responds With
Meaning
GA↵
A+001.100
Request: 1100g.
Note: For preventing errors during the read out of the data, the register ‘GA’ has stored the value
999999 at the beginning of the measurement cycle. The measurement result can only be read after
the defined measuring time ‘MT’ has been elapsed and before a new measurement cycle has been
started.
5.6.8. GL Get Data String (Average, Gross & Status)
Master Sends
Slave Responds With
Meaning
GL↵
L+00100+001005109
(example).
Average Value: +000100dec. (no decimal point).
Gross Value: +001100dec. (no decimal point)
Status bit 1: 5 (Not Used).
Status bit 2: 1hex.
Checksum: 09hex.
For check sum, status bit 1 and status bit 2, see command ‘GW’ (chapter 5.6.5).
5.6.9. OF Output Format for Data String GW & GL
This command puts the range information and/or the decimal point into the ‘long’ data string of the
‘GW’ and ‘GL’ output responses.
Master Sends
Slave Responds With
Meaning
CE↵
E:00012 (example)
Request: TAC Counter CE12.
CE 12↵
OK
Calibration Sequence Active.
OF 1↵
OK
Setup: OF=1
Note: Changes to this command must be saved using the ‘CS’ command. This command also
adds/removes the range field (decimal point is unaffected) for Get Gross ‘GG’ and Get Net ‘GN’
commands.
