3.5.3. Calibration Sequence
Example: Setup of zero-point, span and decimal point.
The chosen calibration weight has the value 5000 (increments). That could be 500g, 5kg or
5000kg. We calibrate with 500g. The decimal point is set up by command DP’x’ (x=1, 2 or 3), here
1 figure after the decimal point. A measured weight of 500g is displayed as 500.0.
Master Sends
Slave Responds With
Meaning
CE↵
E+00019 (example)
TAC Counter=19.
Adjust Zero: The Scale must be Empty – No Load!
CE 19↵
OK
Calibration Sequence Active.
CZ↵
OK
System Zero-Point Saved.
Adjust Gain: First put the Calibration Weight on the Scale (here 500g).
CE 19↵
OK
Calibration Sequence Active.
CG 5000↵
OK
Setting Span.
CG↵
G+005000
Request: Span 5000divisions.
CE 19↵
OK
Calibration Sequence Active.
DP 1↵
OK
Setting Decimal Point 00000.0.
CE 19↵
OK
Calibration Sequence Active.
CS↵
OK
Save Calibration Data.
The zero-point, span and decimal point position were saved into the non-volatile memory; the
calibration counter (TAC) will be incremented.
