EM100-F User Manual
0084293
Page 91 of 93
6.4.3. Heartbeat Message
This is sent by an individual node when the heartbeat protocol is activated. It contains only one
byte, indicating the NMT State.
COB-ID
NMT State
700 + Node ID.
0 = Boot-up.
4 = Stopped.
5 = Operational.
127 = Pre-Operational.
Note: bit-7 is reserved.
6.4.4. Emergency Message
This is sent by an individual node to warn of an error condition in the internal functioning of that
node.
Transmit
EM100->Master
COB-ID 80H+Node ID
Error Code
Error
Registered
Manufacturer Specific Error
Byte 0
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
81
10
81
00
00
00
00
00
00
The above shows the error code 8110 which is CAN overrun (i.e. objects are lost).
Emergency Objects:
Abort Code (Hex.)
Description
8110
Monitoring – CAN Over-run (objects lost).
8120
Monitoring – CAN in error passive mode.
8130
Monitoring – Node Guarding or heartbeat error.
8140
Monitoring – Recovering from bus off.
8210
Protocol – PDO not processed due to error length.
8220
Protocol – PDO length exceeded.
