Page 50 of 93
5.7.6. SL Send Data String Continuously (Average, Gross & Status)
Master Sends
Slave Responds With
Meaning
SL↵
L+00100+001005109
(example).
Average Value: +000100dec. (no decimal point).
Gross Value: +001100dec. (no decimal point).
Status bit 1: 5 (Not Used).
Status bit 2: 1hex.
Checksum: 09hex.
For check sum, status bit 1 and status bit 2 see command ‘SW’ (chapter 5.7.6).
5.7.7. SW Send Data String Continuously (Net, Gross & Status)
Issuing the ‘SW’ command, which has no parameters, will return continuously the net weight, the
gross weight, the status and the checksum values, all combined into one single string in the format:
W+000100+001100010F
For more detailed information of the data string see command ‘GW’ (chapter 5.6.5).
Master Sends
Slave Responds With
Meaning
SW↵
W+000100+0011005109
(example).
Net Value: +000100dec. (no decimal point).
Gross Value: +001100dec. (no decimal point).
Status bit 1: 5hex (Not Used).
Status bit 2: 1hex.
Checksum: 09hex.
STATUS
Value=1
Value=2
Value=4
Value=8
Status Bit-1
Not Used.
Not Used.
Output 1 Active.
Output 2 Active.
Status Bit-2
Signal Stable.
Set Zero Performed.
Tare Active.
Not Used.
The checksum is the reciprocal value of the sum of all ASCII values within the data string without
the check sum itself.
