Flintec EM100-C User Manual

EM100-F User Manual
0084293
Page 65 of 93
5.13.1. DI Filling Status
Issuing the ‘DI’ command will return a result in the format I:000 (only low byte).
Master Sends
Slave Responds With
Meaning
DI↵
I:000
Request: Status Filling.
DI↵
I:068
Status: Dose Program
Running, Tare Out of Range
(No Filling).
This result can be decoded according to the table below:
Low Byte Filling Status
High Byte Filling Status
0 Idle.
0 Idle.
1 Coarse Valve Open.
256 Waiting for 2
nd
Trigger.
2 Fine Valve Open.
512 Bottle On, Calculating Tare.
4 Dose Program Running.
768 Pre-Filling.
8 Not Used.
1024 Main Filling.
16 Not Used.
1280 Fine Filling.
32 Not Used.
1536 In-Flight Delay.
64 Tare Out of Range – No Filling
this Cycle.
1792 Post Fill Calculation.
128 Zero Out of Range.
2048 Post Filling.
5.13.2. SC Start Cycle
Issuing the ‘SC’ command (has no parameters), will start the filling cycle, i.e. the ‘Dose Program
Running’ status bit will be set, the program will wait for a trigger pulse on input 0. If the load-cell
zero-check function is not required, set ‘PD3’ to ‘0’. The system then waits for a trigger pulse on
input 1.
5.13.3. AC Abort Cycle
Issuing the ‘AC’ command (has no parameters), will abort the filling cycle immediately, i.e. the ‘Dose
Program Running’ status bit will be reset, the valves will be shut off and the dosing program will
stop.
