Options and Accessories
Introduction 8
8-3
8-1. Introduction
This chapter describes options and accessories available to enhance the capabilities of the
5700A/5720A Series II Calibrator. Chapter 4 contains instructions for operating the
calibrator with the options and accessories described here. To order options or
accessories, call or write to a Fluke Service Center.
8-2. Wideband AC Voltage Module (Option 5700A-03
The Wideband AC Voltage Module (Option 5700A-03) is used to calibrate RF
voltmaters, and can be installed in either a 5720A or 5700A Series II calibrator. Its
frequency ranges from 10 Hz to 30 MHz , and is a highly accurate, low-noise, ac voltage
source that maintains excellent flatness. The module sources its output through a coaxial
connector into a 50Ω load, and this output can be from within any of seven ranges of
values, from 300 µV (-57 dBm) to 3.5V (+24 dBm), selected in either volts or dBm.
The wideband module also functions with the calibrator’s edit controls, allowing you to
display the error of a wideband meter in percentage of output or decibels.
8-3. Accessories
Included with the wideband module are a Type “N” output cable and a 50Ω terminator.
The wideband module is calibrated to the end of its standard equipment output cable.
Table 8-1 summarizes the accessories available for the 5700A/5720A Series II Calibrator.
Following the table is a brief description of each accessory.
Table 8-1. Accessories
Model Description
732B DC Voltage Reference Standard
742A-1 1Ω Resistance Transfer Standard
742A-10k 10 kΩ Resistance Transfer Standard
5440A-7002
5440A-7003
Low Thermal EMF Test Lead Set with Banana Plugs:
One 4 ft. cable (122 cm) and two 2 ft. (61 cm) cables.
Low Thermal EMF Test Lead Set with Spade Lugs.
Two 4 ft. (122 cm) cables and One 2 ft. (61 cm) cable.
Y8021 IEEE-488 Shilded Interface Cable, 1 Meter
Y8022 IEEE-488 Shielded Interface Cable, 2 Meters
Y5737 24 in (61 cm) Rack Mount Kit for 5700A/5720A Series II
Y5735 24 in (61 cm) Rack Mount Kit for 5725A
PAC33 Printer Adapter Cable, Serial to Parallel Interface
To Next Page
