Fluke 5700A Series II User Manual

Installation
Introduction 2
2-3
WWarning
The calibrator can supply lethal voltages to the front and rear
binding posts. Read this chapter before operating the
calibrator.
2-1. Introduction
This chapter provides instructions for unpacking and installing the calibrator. The
procedures for line voltage selection, fuse replacement, and connection to line power are
provided here. Read this chapter before operating the calibrator.
Instructions for cable connections other than line power connection can be found in the
following chapters of the manual:
• UUT (Unit Under Test) connections: Chapter 4
• IEEE-488 interface bus connection: Chapter 5
• RS-232-C serial interface connection: Chapter 6
• Option 5700-03 Wideband AC Module connection: Chapter 4
• Auxiliary amplifier connections: Chapter 4
2-2. Unpacking and Inspection
The calibrator is shipped in a container designed to prevent damage during shipping.
Inspect the calibrator carefully for damage, and immediately report any damage to the
shipper. Instructions for inspection and claims are included in the shipping container.
When you unpack the calibrator, check for all the standard equipment listed in Table 2-1
and check the shipping order for any additional items ordered. Refer to Chapter 8 for
information about options and accessories. Report any shortage to the place of purchase
or to the nearest Fluke Service Center. If performance tests are required for your
acceptance procedures, refer to the 5700A/5720A Series II Service Manual for
instructions.
If you need to reship the calibrator, use the original container. If it is not available, you
can order a new container from Fluke by indicating the calibrator’s model and serial
number.
Table 2-1. Standard Equipment
Item Model or Part Number
Calibrator 5700A/5720A Series II
Line Power Cord See Table 2-2 and Figure 2-2
5700A/5720A Series II Manual Set 1668111
5700A/5720A Series II Operators Ref Guide 601648
5700A/5720A Series II Remote Prog Ref Guide 601655
5700A/5720A Series II Getting Started 1668111
5700A/5720A Series II Manual CD 1668127
Certificate of Calibration No part number

Fluke 5700A Series II Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0 °C to 50 °C
Storage Temperature	-20 °C to 70 °C
Voltage Range	0 to 1100 V
DC Voltage Range	10 μV to 1100 V
Frequency Range	1 MHz
Humidity	non-condensing
Power Requirements	100 V to 240 V
