Fluke 5700A Series II User Manual

Introduction and Specifications
Calibrating the 5700A/5720A Series II Calibrator 1
1-9
procedure involves no adjustments. It simply ensures internal processes are in control,
and establishes parallel external traceability paths for internal functions such as ac
transfers that are never adjusted or corrected.
Figure 1-1 illustrates the time and money that can be saved by using the 5700A/5720A
Series II calibration support plan recommended by Fluke. Depending on your policies,
you may initially decide to perform calibration verification more often. The calibrator
makes this unnecessary and offers you a practical way to collect data unavailable with a
traditional calibrator design about performance between calibrations.
COST $
COST $
CALIBRATION CYCLE
CALIBRATION CYCLE
TRADITIONAL CALIBRATOR CALIBRATION
5700A/5720A SERIES II CALIBRATION
TIME
TIME
Figure 1-1. Time and Costs: Calibrator Calibration

Fluke 5700A Series II Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0 °C to 50 °C
Storage Temperature	-20 °C to 70 °C
Voltage Range	0 to 1100 V
DC Voltage Range	10 μV to 1100 V
Frequency Range	1 MHz
Humidity	non-condensing
Power Requirements	100 V to 240 V
