Fluke 5700A Series II User Manual

5700A/5720A Series II
Operators Manual
C-2
D4G 22V range positive gain
Name Description
D4N 22V range negative gain
D5P 220V range zero offset
D5G 220V range gain
D6P 1100V range zero offset
D6G 1100V range gain
KRMS AC V sense return buffer offset
OSUP Upward 15-bit dac hysteresis offset
OSDN Downward 15-bit dac hysteresis offset
A1G 2.2 mV range gain
A1S 2.2 mV range standing wave ratio correction
A2G 22 mV range gain
A2S 22 mV range standing wave ratio correction
A3G 220 mV range gain
A3S 220 mV range standing wave ratio correction
A4G 2.2V range gain
A4S 2.2V range standing wave ratio correction
A4D 2.2V range 8-bit dac constant
A4F1 2.2V range, flatness correction, 20 kHz
A4F2 Same, 50 kHz
A4F3 Same, 100 kHz
A4F4 Same, 119.99 kHz
A4F5 Same, 120 kHz
A4F6 Same, 200 kHz
A4F7 Same, 300 kHz
A4F8 Same, 400 kHz
A4F9 Same, 500 kHz
A4FA Same, 600 kHz
A4FB Same, 700 kHz
A4FC Same, 800 kHz
A4FD Same, 900 kHz
A4FE Same, 1 MHz
A4FF Same, 1.1 MHz

Fluke 5700A Series II Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0 °C to 50 °C
Storage Temperature	-20 °C to 70 °C
Voltage Range	0 to 1100 V
DC Voltage Range	10 μV to 1100 V
Frequency Range	1 MHz
Humidity	non-condensing
Power Requirements	100 V to 240 V
