Fluke 5700A Series II User Manual

Appendices
Symbolic Names of Calibration Constants
C
C-7
A6FL Spare
A7G 1100V range gain
A7F1 1100V range, first flatness correction, 300 Hz
A7F2 Same, 500 Hz
A7F3 Same, 700 Hz
A7F4 Same, 1 kHz
Name Description
A7F5 Spare
A7F6 Spare
I1Z 220 µA range zero
I1G 220 µA range gain
I2Z 2.2 mA range zero
I2G 2.2 mA range gain
I3Z 22 mA range zero
I3G 22 mA range gain
I4Z 220 mA range zero
I4G 220 mA range gain
I5Z 2.2A range zero
I5G 2.2A range gain
IGME Measurement at bottom of resistor during gain cal
I1F1 220 µA ac, 500 Hz
I1F2 Same, 1 kHz
I1F3 Same, 2 kHz
I1F4 Same, 5 kHz
I1F5 Same, 7 kHz
I1F6 Same, 10 kHz
I1F7 Spare
I1F8 Spare
I2F1 2.2 mA ac, 500 Hz
I2F2 Same, 1 kHz
I2F3 Same, 2 kHz
I2F4 Same, 5 kHz
I2F5 Same, 7 kHz
I2F6 Same, 10 kHz

Fluke 5700A Series II Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0 °C to 50 °C
Storage Temperature	-20 °C to 70 °C
Voltage Range	0 to 1100 V
DC Voltage Range	10 μV to 1100 V
Frequency Range	1 MHz
Humidity	non-condensing
Power Requirements	100 V to 240 V
