Fitting the interconnecting hosepack
Fitting the PAP
interconnecting
hosepack to the
robot
NOTE!
The mounting of the holder for the interconnecting hosepack depends on the
robot manufacturer and robot type.
▶
Mount the holder for the interconnecting hosepack according to the Installation
Instructions for the respective robot.
1 2
3
Lay the interconnecting hosepack in the clamps
4
Close the clamps
103
EN
