Fronius TPS/i Push - Fitting the Interconnecting Hosepack; Fitting the Standard Interconnecting Hosepack to the Robot; Connecting the Extension Hosepack

Fitting the interconnecting hosepack
Fitting the Stand-
ard interconnect-
ing hosepack to
the robot
3 Nm
2.21 lb-ft
1 2
Connecting the
extension hosep-
ack
CAUTION!
Danger from electric current due to inadequate connections.
This can result in serious injury and damage to property.
▶
All cables, leads and hosepacks must be properly connected, undamaged, correctly
insulated and adequately dimensioned.
1
* Only on water-cooled hosepack
CON = Interconnecting hosepack
EXT = Extension hosepack
