Fronius TPS/i Push User Manual

Fitting the clamp system
Special tilt angle
for the welding
torch
The positioning of the welding torch in relation to the workpiece is divided into fixed
angles by the torque angle gauge. Special angles are available on request.
12,5°
259
61
320
34,5°
38
- CrashBox /i
- Indexdisk 22°
- Clamp TPS/i
- MHP 700i W R/FSC/0,95m
- MTB 500i W R/22°/L241/H50
- CrashBox /i
- Indexdisk 22°
- Clamp TPS/i
- MHP 400i R /G/FSC/1,45m
- MTB 400i G R /36°/L224/H86
12,5°
235
61
296
48,5°
69
31
12,5°
216
61
277
57,5°
87
49
- CrashBox /i
- Indexdisk 22°
- Clamp TPS/i
- MHP 700i W R/FSC/1,45m
- MTB 500i W R/45°/L209/H107
4,95°
262
61
323
26,95°
34
4
- CrashBox /i
- Indexdisk 36°
- Clamp TPS/i
- MHP 700i W R/FSC/1,25m
- MTB 500i W R/22°/L241/H50
4,95°
242
61
303
40,95°
38
- CrashBox /i
- Indexdisk 36°
- Clamp TPS/i
- MHP 700i W R/FSC/1,25m
- MTB 500i W R/36°/L224/H86
4,95°
226
61
286
49,95°
58
20
- CrashBox /i
- Indexdisk 36°
- Clamp TPS/i
- MHP 700i W R/FSC/0,95m
- MTB 500i W R/45°/L209/H107
0°
261
61
322
22°
58
19
- CrashBox /i
- Indexdisk 45°
- Clamp TPS/i
- MHP 400i R /G/FSC/0,95m
- MTB 400i G R /22°/L241/H50
0°
244
61
305
36°
21
17
- CrashBox /i
- Indexdisk 45°
- Clamp TPS/i
- MHP 400i R /G/FSC/1,25m
- MTB 400i G R /36°/L224/H86
0°
230
61
291
45°
38
- CrashBox /i
- Indexdisk 45°
- Clamp TPS/i
- MHP 700i W R/FSC/1,45m
- MTB 500i W R /45°/L209/H107
67
