Fitting the MHP G / W hosepack
Fitting the MHP
G / W conven-
tional hosepack -
Standard
1 2
6,5 Nm
4.79 lb-ft
3 4
Optimum hosep-
ack arrangement
R
R
R ≥ 200 mmR < 200 mm
69
EN
