Fronius TPS/i Push - Technical Data; Fitting the OptI MHP Wirebrake

Technical data
TCP offset 47 mm
1.85 in.
Wire diameter 0.8 - 1.6 mm
0.03 - 0.06 in.
Weight 450 g
0.99 Ib.
Fitting the OPT/i
MHP WireBrake
1
3 x 0,1 Nm
3 x 0.07 lb-ft
2
1
ONLY
when p > 5,5 bar / 79.74 psi
3
1
4
NOTE!
The front O-ring must only be removed at a system pressure of > 5.5 bar / 79.74 psi
(step 3).
At a system pressure of < 5.5 bar / 79.74 psi, the second O-ring remains on the WireB-
rake option.
82
