WF 25i REEL R /4R, WF 30i REEL R /2R
Safety
WARNING!
Incorrect operation or shoddy workmanship can cause serious injury and damage.
▶
The following documents must be completely read and understood before commis-
sioning the unreeling wirefeeder:
these Operating Instructions
the Operating Instructions of the power source in use
the Operating Instructions of all other system components
the safety rules and safety instructions in the above-mentioned documents.
CAUTION!
Risk of injury from rotating drive parts if covers are open.
▶
When performing maintenance or set-up work, make sure that the drive components
of the unreeling wirefeeder cannot be started by the power source, by a wirefeeder
or by any other system add-ons.
Device concept The unreeling wirefeeder is an extra drive unit for ensuring constant and precision
wirefeeding over large wirefeeding distances between the welding wire drum and the
robot wirefeeder.
While in operation, the unreeling wirefeeder is synchronised with the power source.
It is supplied with power and controlled by the power source in the welding system.
The unreeling wirefeeder is available in two versions:
- WF 25i REEL R /4R
Integrated version with 4-roller drive
- WF 30i REEL R /2R
Integrated version with 2-roller drive - not permitted in conjunction with a basket-type
spool
Application area All indoor and automated MIG/MAG applications.
Proper use The device is designed exclusively for wirefeeding in automated MIG/MAG welding
applications in conjunction with Fronius system components. Any use above and beyond
this purpose is deemed improper. The manufacturer shall not be held liable for any dam-
age arising from such usage.
Utilisation in accordance with the intended purpose also comprises:
- carefully reading these operating instructions
- following all the instructions and safety rules in these operating instructions
- performing all stipulated inspection and maintenance work
Warning notices
on the device
The device is fitted with safety symbols and a rating plate. The safety symbols and rating
plate must not be removed or painted over. The safety symbols warn against operating
the equipment incorrectly, as this may result in serious injury and damage.
34
