WF 25i REEL R /4R, WF 30i REEL R /2R
Safety
WARNING!
Danger from incorrect operation.
This can result in severe personal injury and damage to property.
▶
All the functions described may only be used by trained and qualified personnel.
▶
Fully read and understand this document.
▶
Fully read and understand all the Operating Instructions for the system components,
especially the safety rules.
Controls, connec-
tions and mech-
anical compon-
ents
(1)(3) (2)
Front of WF 25i REEL R /4R/G/W
(1)(5) (4)
Front of WF 30i REEL R /2R/G/W
(6)(7)
Left side
(11) (8)
(9)
(10)
Rear
