Warning notices
on the device
The device is fitted with safety symbols and a rating plate. The safety symbols and rating
plate must not be removed or painted over. The safety symbols warn against operating the
equipment incorrectly, as this may result in serious injury and damage.
Welding is dangerous. The following
basic requirements must be met to en-
sure the equipment is used properly:
- Welders must be sufficiently quali-
fied
- Suitable protective equipment
must be used
- All persons not involved must be
kept at a safe distance from the
wirefeeder and the welding pro-
cess
Do not use the functions described here
until you have fully read and under-
stood the following documents:
- These operating instructions
- all the operating instructions for the
system components, especially
the safety rules
Do not dispose of used devices with do-
mestic waste. Dispose of them accord-
ing to the safety rules.
Keep hands, hair, clothing and tools away from moving parts. For example:
- cogs
- feed rollers
- wirespools and welding wires
Do not reach into rotating drive components.
Covers and side panels may only be opened or removed for as long as mainte-
nance or repair work is being carried out.
During operation:
- Ensure that all covers are closed and all side panels are fitted properly.
- Keep all covers and side panels closed.
40,0006,3035
Caution:
Attention:
Parts may be at welding
voltage
Les pièces peuvent être
à la tension de soudage
500 A/100% 600 A/60% 650A/40%
I2
0.8 AI
11
U11
60 V
U
12 I12 0.5 A24 V
IEC 60 974-1/-10 Cl.A IP 43
www.fronius.com
Ser.No.:
Part No.:
XXXXXXXXXX
4,040,080
SB 500i R /G/W/FSC
