Fronius TPS/i Robotics PushPull CMT - Fitting SplitBox and CrashBox Components

61
EN
Fitting the SplitBox
Fitting the wire-
feeder holder
Fitting the SB
500i R
1 2
* = 2x M8 x 20 mm
Fitting the SB
500i R (left vari-
ant)
1 2
* = 2x M8 x 20 mm
NOTE! Depending on the robot, please also note the instructions and information
on installing the wirefeeder in the leaflets listed below:
7x
M6x16
6x
6FSt
6FSt
1x
1x
M6x16
1
2
7x
M6x16
6x
6FSt
6FSt
1x
1x
M6x16
1
2
