Fitting the interconnecting hosepack
Fitting the PAP in-
terconnecting
hosepack to the
robot
1 2
3
IMPORTANT! Values for the "a" and "b" di-
stances can be found in the leaflets for the
different robot manufacturers.
Connecting the
extension hose-
pack
1
* Only on water-cooled hosepack
CON = interconnecting hosepack
EXT = extension hosepack
1
2
3
CAUTION! Risk of injury and damage from loose connections. All cables, leads
and hosepacks must be properly secured, undamaged, insulated and adequately
dimensioned.
