99
EN
Connecting the SplitBox to the system components
Safety
General
Connecting the
SplitBox to the
system compo-
nents
IMPORTANT! Whenever the torch hosepack is fitted or removed, ensure that the coupling
point is clean and dry. Remove any coolant that has escaped from the coupling point.
1 2
3 4
WARNING! An electric shock can be fatal. Before starting the work described be-
low:
- turn the power source mains switch to the "O" position
- disconnect the power source from the mains
- ensure that the power source remains disconnected from the mains until all
work has been completed
CAUTION! Risk of injury and damage from loose connections. All cables, leads
and hosepacks must be properly secured, undamaged, insulated and adequately
dimensioned.
NOTE! Also follow the instructions and information in the documents
42,0410,1946 and 42,0410,2010 when connecting the wire-feed unit to the sys-
tem components.
1
2
3 4
