Additional information for TWIN systems:
- TWIN systems are only compatible with the OPT/i RI FB REL EXT 8I/8O option
- The signals are forwarded to both power sources and are then available at the out-
puts of the relay station used
Job number
(Job‑number) -
Group Input
This signal is used to carry out welding using the welding parameters that are saved
under the selected job number (1-1000).
Job number 0 can be used to select the job on the control panel of the power source.
Additional information for TWIN systems:
Job numbers must be selected separately for both power sources.
Welding charac-
teristic (Charac-
teristic number) -
Group Input
This signal is used to specify the welding process using the characteristic number.
Characteristic number 0 can be used to select the material setting and the welding pro-
cess on the control panel of the power source.
Examples of characteristic numbers:
- 2765 = G3Si1 / 1.2 mm / Ar 15-20%, CO2 / LSC
- 3189 = G3Si1 / 1.2 mm / Ar 15-20%, CO2 / PMC
Additional information for TWIN systems:
Characteristic numbers must be selected separately for both power sources.
Disable process
control (Deactiv-
ate process-
dependent cor-
rection) - Group
Input
If this signal is active, a process-dependent correction (Process controlled correction sig-
nal) can be manually selected on the power source.
Additional information for TWIN systems:
Process-dependent corrections must be activated separately for both power sources.
Processline
select (Process
line selection) -
Group Input
This signal is used to select the desired process line.
The signal is only available if:
- The OPT/i TPS Dual Head Robotics option is present in the power source
- Each process line has its own wirefeeder
Bit 1 Bit 0 Description
0 0 Wirefeeder 1 (factory setting)
0 1 Wirefeeder 2
1 0 Wirefeeder 3
16
